ONETRACK READY L32 UGR - SINGLE MODULE BI-EMISSION
ONETRACK READY L32
ONETRACK READY L32 UGR - SINGLE MODULE BI-EMISSION
Modulo singolo per luce lineare a 230V. Luce biemissione. Corpo in alluminio. Riflettore UGR in policarbonato. Cover in poliammide.
Products are updated regularly, visit luxtron.net for an updated product list.Page 1
ONETRACK READY L32 UGR - SINGLE MODULE BI-EMISSION
technical specifications
ONETRACK READY L32 UGR - SINGLE MODULE BI-EMISSION
Modulo singolo per luce lineare a 230V. Luce biemissione. Corpo in alluminio. Riflettore UGR in policarbonato. Cover in poliammide. L(mm): 1406.
Track fixtures from
A.A.G. Stucchi

Technical Data

Item codeL32S524/W21-U-2
ColourWhite
Control systemDALI
FamilyStandalone
Product lineONETRACK READY L32
CCT3000 K
OpticsUGR REFLECTOR (U)
Length1406 mm
CRI90
Luminous flux4137 lm
Power52.2 W
Efficiency79.3 lm/W
UGR<16
MacAdam≤ 3
Lifetime>50Khr L90B10
Variants8
Products are updated regularly, visit luxtron.net for an updated product list.
Original datasheetPage 2
ONETRACK READY L32 UGR - SINGLE MODULE BI-EMISSION
dimensions
Dimension drawing
Products are updated regularly, visit luxtron.net for an updated product list.Page 3
