12x Modular Panels
A simple and classic design of control panels with a range of button layouts and finishes
| Protocol | DALI |
| DALI supply input | 12–22.5 V |
| DALI consumption | 10 mA |
| IR frequency | 36 kHz |
| Connection | Removable connector block, 0.5–1.5 mm² solid or stranded |
| Module dimensions | 35.4 × 31.8 × 48.4 mm |
| Weight | 41 g with DALI connector |
| Colours | White (RAL 9016), Anthracite Grey (RAL 7016) |
| IP rating | IP30 |
| Ambient temperature | 0 °C to +50 °C |
| Frames | Satin white plastic 200S / 200D, stainless steel 232S / 232D (single / double gang) |
| Designer / Toolbox | 5.2.0 or later / 2.4.2 or later |
